Met Ocean Sensors

Our systems are especially designed for the offshore oil and gas market, and are suitable for productions platforms and drilling rigs. This includes FPSOs, Semi-Subs, jack-ups, drill ships as well as jacket and GBS platforms.

System Functionality

The system may encompass functionality addressing the operational needs for:

  • General Met-Ocean Information
  • Support for Helicopter landing and take-off Operations
  • Support for Marine Operations
  • Aviation Weather Observation
  • Maritime Weather Observation
  • Oil Spill Surveillance
  • Data Logging for structure verification and incident investigation
  • Reporting of climatological data

Meteorological Sensor

  • Wind speed and direction sensors
  • Air pressure sensors
  • Met-shelter with air temperature and humidity sensors
  • Cloud level sensor
  • Visibility and Present Weather sensor
  • Solar radiation sensor
  • Rainfall / Precipitation sensor

Directional Wave Sensor

Miros SM-050 Wave and Current Radar™
A highly accurate and robust directional wave and surface current sensors utilizing pulse Doppler technique.

Miros Wavex®
Utilizing back scatter from standard marine x-band radars, providing directional wave and surface current data.

Non-Directional Wave Sensor

Miros SM-140 RangeFinder™
An highly accurate sensor for wave, air gap and water level measurements.
The SAAB Rex is an alternative sensor for use in hazardous areas.

Current and Subsea Sensors

  • Acoustic Doppler Current Profilers (ADCP)
  • Horizontal-ADCP
  • Point Sensors
  • Sea temperature, conductivity and salinity sensors
  • ADCP Hoisting Systems
  • Pneumatic systems for deploying ADCPs and similar sensors from
    FPSO’s Semi-subs, jackets etc.

 Other Sensors

  • Vessel Motion Sensors (Seatex’ range of MRUs)
  • GPS
  • Gyro
  • X-band radars for Wavex

SYSTEM FUNCTIONALITY

The system may encompass functionality addressing the operational needs for:

  • General Met-Ocean Information
  • Support for Helicopter landing and take-off Operations
  • Support for Marine Operations
  • Aviation Weather Observation
  • Maritime Weather Observation
  • Oil Spill Surveillance
  • Data Logging for structure verification and incident investigation
  • Reporting of climatological data

SOFTWARE

The software is based on a client / server philosophy. Real time and historical data are stored in an Oracle database, easily accessible by other systems. Data may be stored in dedicated history files for long term data storage, on formats suitable for further offline processing. The software will normally run on servers using Windows Server OS. The servers may be dedicated ones, or a virtual server in a company server cluster.

General purpose and dedicated User Displays are available. Data from various platforms available on the same LAN may be accessed by the same User Display software.
